General
Net Weight2.68 kg (5.91 lb)
Gross Weight3.6 kg (7.94 lb)
Dimensions (W × H × D)440.00 mm × 45.00 mm × 230.00 mm (17.32'' × 1.77'' × 9.06'')
Operating Temperature0 °C to 45 °C (32 °F to 113 °F)
Operating Humidity5% to 95% (no condensation)
Power Supply100-240 VAC, 50 Hz ± 10%
Power Consumption< 15W
Network Parameters
MAC Address Table8 K
Ports24 × 1 Gigabit RJ45 port,4 × 1 Gigabit fiber optical port
Switching Capacity
Whole-Device Performance: 56 Gbps
Port Performance: 56 Gbps
Packet Forwarding Rate
Whole-Device Performance: 41.66 Mpps
Port Performance: 41.66 Mpps
Software Function
VLAN4K VLAN, GVRP, QinQ, Private VLAN
QoS
Flow classification based on L2 to L4 protocols
CAR flow limit
802.1P/DSCP priority re-labeling
SP, WRR, and SP+WRR\"
Congestion avoidance mechanisms like Tail-Drop and WRED
Flow monitoring and flow shaping
Multicast
IGMP v1/v2/v3
IGMP snooping
IGMP Fast Leave
Multicast group strategy and quantity limitation
Management Method
Console, Telnet, SSH2.0, Web
SNMP v1/v2/v3
TFTP
RMON
Security
L2/L3/L4 ACL flow identification and filtration
DDoS attack prevention, TCP's SYN Flood attack prevention, UDP Flood attack prevention, etc.
Broadcast/multicast/unknown unicast storm-control
Port isolation
Port security, and IP+MAC+port\" binding"
Approval
EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 22)
SafetyUL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2032)
ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2021)
