| PERFORMANCE |
| Processor |
Intel Core™ i3-14100, 4C (4P + 0E) / 8T, P-core 3.5 / 4.7GHz, 12MB Intel® Smart Cache |
| Graphics |
Integrated Intel® UHD Graphics 730 |
| Chipset |
Intel® B760 Chipset |
| Memory |
1x 8GB UDIMM DDR5-4800 |
| Memory Slots |
Two DDR5 UDIMM slots, dual-channel capable |
| Max Memory |
Up to 64GB DDR5-5600 |
| Storage |
256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
| Max Storage Support |
- Up to three drives, 1x 3.5"HDD + 1x 2.5"HDD + 1x M.2 SSD
- • 3.5" HDD up to 2TB
- • M.2 SSD up to 1TB
- • 2.5" HDD bay is only for customer self upgrade
|
| Card Reader |
3-in-1 Card Reader |
| Optical |
DVD±RW |
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC623-CG codec |
| Speakers |
2Wx1 |
| Power Supply |
180W 85% |
| DESIGN |
| Keyboard |
USB Calliope Keyboard, Black, Hebrew |
| Mouse |
USB Calliope Mouse, Black |
| Optional Bay |
None |
| Expansion Slots |
- One PCIe® 3.0 x16, full-height, length ≤ 233.6mm, height ≤ 117.5mm
- One PCIe® 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm)
- Two M.2 slots (one for WLAN, one for SSD)
|
| Case Color |
Black |
| System Fan |
None |
| Toolless Chassis Screw |
Toolless Chassis Screw |
| Pen |
Pen Not Supported |
| Form Factor |
Tower (13.6L) |
| Dimensions (WxDxH) |
145 x 294 x 340 mm (5.71 x 11.57 x 13.39 inches) |
| Weight |
Around 5.6 kg (12.35 lbs) |
| CONNECTIVITY |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.2 |
| WWAN |
WWAN Not Supported |
| Ethernet |
RTL8111K, 1x RJ-45 |
| Front Ports |
- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with data transfer and 15W charging
- 4x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports |
- 4x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4a (HBR2)
- 1x VGA
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) |
None |
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified |
| Physical Locks |
- Kensington Security Slot™
- Padlock Loop
|
| Smart Cable Clip |
None |
| Chassis Intrusion Switch |
Chassis Intrusion Switch |
| MANAGEABILITY |
| System Management |
None |
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in |
| Included Upgrade |
3Y Onsite from 1Y Courier/Carry In SEE (CPN) |
| CERTIFICATIONS |
| Green Certifications |
- RoHS / WEEE / REACH
- TCO Certified 9.0
|
| SOFTWARE |
| Operating System |
None |
| Bundled Software |
None |
| ACCESSORIES |
| Bundled Accessories |
None |
